Page #17 background imageLoading...
Page #17 background image
CHAPTER 2 | DEVICE PROGRAMMING UNIT USER’S MANUAL
PROGRAMMING 13
Press RE-DO to return to the top level of the
programming display. Press EXIT to escape from
programming and return to the Main Menu. When
the device is removed, the DPU will return to the
first programming screen.
When programming or testing HTRI-S/-D/-R/-M,
HMS-S/-D/-M/-2S/-SA or FDCIO422 devices, the polarity
of the programming cable (position of locating tab) is not
important because the devices are not sensitive to
polarity.
MXL Detectors and Devices
Since some MXL detectors use the older DB-3S base, it
is necessary to connect the base adaptor, P/N 515-
033925, supplied with the DPU in order to program
these devices. Refer to Figure 2 on pages 10-11 to
connect the device to be programmed.
In addition to programming the address, the DPU allows
usage information to be programmed into MXL devices
and detectors; therefore, the screens presented to the
user will vary depending on the device being programmed.
Smoke Detectors
To program an MXL smoke detector, the system
must be set to MXL (refer to page 6.) Begin with
the DPU displaying the Main Menu and then press
the PROGRAM button. The DPU will prompt the
user to insert or connect a device or detector. When
the DPU finds the detector, it will display the
detector type on the first line of the display. The
following screen is an example of an FP-11 detector:
FP-11
LOOP=012 ADDRESS=41
<ID SETTINGS>
<EXIT PROGRAM>
