CHAPTER 2 | DEVICE PROGRAMMING UNIT USER’S MANUAL
PROGRAMMING 21
1ELBAT
SECIVEDELBITAPMOCDRAWKCAB
eciveDlautcA etalumEnaCeciveDlautcAhcihWseciveDelbitapmoCdrawkcaB
11-PF T
P06-DI/P06-DI1-TPLI/1-PLI2-PLI
2-PLI TP06-DI/P06-DI1-TPLI/1-PLI
11-TPF T06DI/1-TLI
1-TPLI/1-PLI TP06-DI/P06-DI
H1-ILI/1-ILI H06-DI/I06-DI
HA1-ILI/A1-ILI HAI06-DI/AI06-DI
HB1-ILI/B1-ILI HBI06-DI/BI06-DI
FS-100 Detectors and Devices
Usage and configuration information for FS-100 devices
and detectors may only be programmed by the panel or
configuration tool. The DPU is only capable of setting the
address of these devices.
Smoke Detectors
To program an FS-100 smoke detector, the system
must be set to FS-100 (refer to page 6.) Begin with
the DPU displaying the Main Menu and then press
the PROGRAM button. The DPU will prompt the
user to insert or connect a device or detector. When
the DPU finds the detector, it will display the
detector type on the first line of the display. The
following screen is an example of an FS-DPT
detector:
FS-DPT
ADDRESS=41
ADDRESS>
<EXIT PROGRAM>
