DEVICE PROGRAMMING UNIT USER’S MANUAL | CHAPTER 2
24 PROGRAMMING
• If the settings are correct, press PROGRAM to
program the device. If label printing is selected, up
to nine labels will be printed. If the device is
programmed correctly, the display will appear similar
to the following:
FS-TRI AL NO
ADDRESS=41
PROGRAMMED OK
<EXIT CHANGE>
Press EXIT to return to the Main Menu. Use the
CHANGE button to go back and change a setting.
• If the device was not programmed correctly, the
display will appear similar to the following:
FS-TRI AL NO
LOOP=1 ADDRESS=41
PROGRAMMING FAILED
<EXIT RE-DO>
Press EXIT to return to the Main Menu. Press RE-DO
to reprogram the detector.
• If the device was programmed correctly and the
device is removed, the ”searching” screen will
display.
FS-TRI-D
FS-TRIs must be programmed using cable P/N 555-
133891 that is stored in the cable compartment in the
bottom of the DPU. Before starting to program FS-TRIs,
open the cable compartment and insert the program-
ming plug in one end of the cable into the red and black
banana jacks in the cable compartment of the unit. (Refer
to Figure 2, pages 10-11.) Then follow the procedure
below:
• With the DPU displaying the Main Menu, press the
PROGRAM button. The DPU will prompt the user to
insert or connect a device or detector.
