CHAPTER 2 | DEVICE PROGRAMMING UNIT USER’S MANUAL
PROGRAMMING 15
Press EXIT to return to the Main Menu. Press RE-DO
to reprogram the detector.
When the detector is removed from the socket, the
DPU will return to the top programming screen and
will increment the address.
TRI-S, TRI-R, TRI-M
TRI interface modules must be programmed using cable
P/N 555-133891 that is stored in the cable compartment
in the bottom of the DPU. Before starting to program
TRIs, open the cable compartment and insert the
programming plug in one end of the cable into the red
and black banana jacks in the cable compartment of the
unit. (Refer to Figure 2, pages 10-11.) Then follow the
procedure below:
With the DPU displaying the Main Menu, press the
PROGRAM button. The DPU will prompt the user to
insert or connect a device or detector.
The DPU is not equipped with polarity reversal for TRI devices,
and MS manual stations. If the display searches for a device
for longer than two seconds, reverse the polarity of the
programming cable.
Connect the programming cable to the device to be
programmed. (Refer to Figure 2, pages 10-11.) When
the DPU has detected the device, the display will
appear similar to the following:
TRI AL NO
LOOP=012 ADDRESS=41
SETTINGS>
<EXIT PROGRAM>
The top line of the display indicates the device type,
the device usage and the contact state of the input.
