Siemens FC72x User Manual

System overview
Station
overview
3
14 | 62
Building Technologies
A6V10211094_f_en_
--
Fire Safety
2015
-
12
-
15
3.1 Station overview
FC722
fire control panel
(2-loop)
FC724
fire control panel
(4-loop)
FT724
fire terminal
Max. C-NET addresses 252 * 504 * ―
Without loop extension 2 loops * 4 loops * ―
With loop extension 4 loops * 8 loops * ―
Supply
Power supply 70/150 W 150 W optional (70 W)
Batteries (capacity) max. 2x 26 Ah max. 2 x 26 Ah optional (7 Ah)
External DC supply 24 V ― ― redundant
Operating unit integrated integrated integrated
Inputs and outputs
RT alarm, relay 1 1 ―
RT fault, relay 1 1 ―
RT alarm monitored 1 1 ―
RT fault monitored 1 1 ―
Outputs for monitored, acoustic
signal transmitter
1 2 ―
Freely configurable
inputs/outputs
8 12 ―
Options
Loop extension (C-NET) max. 1 max. 2 ―
Network module (SAFEDLINK) max. 2 max. 2 max. 2
Ethernet switch (modular) max. 1 max. 1 external
Repeater (SAFEDLINK) max. 1* max. 1* max. 1*
RS232 / RS485 module max. 2 max. 2 max. 2
Fire brigade periphery module
[DE]
1 1 ―
Event printer 1 1 1
LED module; 24 red/green and
yellow LEDs each
max. 5 max. 5 max. 5
EVAC-NL operating unit [NL] max. 1 max. 1 max. 1
Sounder module max. 2 max. 2 ―
RT interface [NL] max. 1 max. 1 ―
License keys max. 1 max. 1 max. 1
Key switch
(Kaba type)
max. 1 max. 1 max. 1
* Note system limits!
The description of system components and options does not form part of these
brief instructions (For detailed information, refer to the system documentation).
[DE] option for Germany [NL] option for the Netherlands
