Figure 2: Module Location in 1HU Enclosure and Recommended Wire Routing
Modules Location in FHB2001
-
U1/R1
7 FN2006-U1 /FN2007-U1
11- FHA2031-U1
12 FTI2001-U1
Recommended Wiring Routes:
- Knockouts: 1, 2, 3, 4 are for Power Limited wiring only
Notes: Refer to Table 5 to locate each module wiring
diagram.
