Siemens FCA2018-U1 User Manual

Siemens Industry, Inc.
Building Technologies Division
A6V10315044_enUS_c6
INSTALLATION The FCA2018-U1 mounts with two flanges on the side of the terminal block covers.
Select a smooth surface within 6 feet of the PAL-1 for the FCA2018-U1.
Position the FCA2018-U1 and attach it to the mounting surface using the four #6 self
tapping screws provided.
Install the terminal block covers using the 6 remaining #10 nuts. Refer to Figure 3.
ELECTRICAL RATINGS
24V Back Plane Current 0
Screw Terminal 24V Current 150mA Max.
6.2V Back Plane Current 0
24V Standby Current 150mA Max.
Output Power
CAN Network Pair
8V peak to peak max.
75mA max.
(during msg transmission)

Siemens FCA2018-U1 Specifications

General

Brand	Siemens
Model	FCA2018-U1
Category	Control Unit
Language	English
