1 About this document
Goal and purpose
This document contains all the information you'll need to mount and install the
following aspirating smoke detectors:
 FDA241
 FDA221
Following the instructions consistently will ensure that the devices can be mounted
and installed safely and without any problems.
You will find more information about the aspirating smoke detectors in document
A6V10334410. See the chapter 'Applicable documents [➙ 5]'.
Intended use
Aspirating smoke detectors FDA241 and FDA221 may only be used for fire
detection and fire control purposes.
1.1 Applicable documents
Document ID
Title
007023 Technical manual Input module, input/output module FDCI222,
FDCIO222, FDCIO224
008331 List of compatibility (for 'Sinteso™' product line)
009052 FS20 Fire detection system - Commissioning, Maintenance,
Troubleshooting
A6V10210416 FS720 Fire detection system - Commissioning, Maintenance,
Troubleshooting
A6V10229261 List of compatibility (for 'Cerberus™ PRO' product line)
A6V10331032 Data sheet Aspirating Smoke Detectors FDA221, FDA241
A6V10332759 Installation, Operation Manual, Configuration 'ASD
Configuration Tool FXS2051'
A6V10334410 Technical manual Aspirating smoke detector FDA241, FDA221
A6V10334435 Planning, Installation ASD Pipe system
A6V10393194 Technical manual Power supply kit A 70 W FP120-Z1
1.2 Technical terms
Term
Explanation
ASD Aspirating smoke detector
FDnet/C-NET Addressed detector line
GPI
G
eneral
P
urpose
I
nput, connection for an external switch
n.c.
n
ormally
c
losed, connection closed in normal condition
n.o.
n
ormally
o
pen, connection open in normal condition
5
