Siemens FN2012-A1 Installation

5 Jumper settings on the VN2001
The slots the jumpers are plugged into on the Ethernet module (electric) differ
depending on how the module will be used. The table below shows the different
settings for the corresponding function.
X102
1
24V-RxT
GND
-
24V-TxT
GND
-
1
8
X102
Figure 16: View of VN2001 with jumper strip
X102 jumper strip
Jumper setting on X102 Function
1
2
3
4
5
6
7
8
Ground fault supervision activated
1
2
3
4
5
6
7
8
PoE activated
1
2
3
4
5
6
7
8
Neutral position, function deactivated
Jumper settings on the VN2001
5
20 | 32 A6V10407862_e_en_--
