Admissible cable cross-section: AWG24...AWG12 / 0.2...2.5mm²
F1
F2
F3
F4
FAULT
Terminal Plug
Connector
Cover cap
(open)
F4
F3
F2 F1
IN OUT
Pin assignments
'POWER' connector strip
6
A6V10407862_e_en_-- 23 | 32
