Installation
Anchoring
and
Leveling
Outdoor
Shelter
-
Clad
Switchgear
In
Shelter
-
Clad
arrangements
,
the
switchgear
(
as
shipped
)
is
true
and
in
correct
position
relative
to
its
support
base
.
The
formed floor
sections
are a
permanent
part
of
the
switchgear
,
and
are
not to
be loosened
or
moved
from
position
.
Verify
the anchor bolt locations
in
the
concrete
and
all
points
shown
in
the
general
arrangement
plan
view
.
Sweep
the
foundation
to
make certain
it
is
free
of
pebbles
and other debris
.
Check
the
general
arrangement
drawing
for
positioning
of
the
switchgear
and
sequence
of
installation
if
arrangement
consists
of
more
than
one
shipping
group
.
Single
-
aisle
Shelter
-
Clad
cubicles
are
shipped
with
the
aisle wall
covering
the circuit breaker drawout
compartment
.
This wall
may
be removed
before
moving
the
switchgear
into
position
on
its
foundation
,
if
conduit
clearances
are
in
doubt
,
of
if
the
aisle is
to
be assembled
immediately
after
leveling
.
1
.
Remove
seal material
at
top
of
aisle wall
.
2
.
Unbolt
,
remove
,
and
scrap
the
1
-
1
/
4
"
plate
and
1
-
1
/
4
"
angle
.
3
.
Support
wall
with
crane or
other
means
.
(
Allow
approximately
125
lb
.
(
57
kg
)
per
unit
)
and
remove
the
two
angles
at
each end
of
the
group
which
hold the aisle wall
in
place
.
These
angles
can now
be
scrapped
.
Carefully
lay
aside aisle wall until
needed
for
aisle
assembly
.
4
.
Remove
nuts
from
all anchor bolts
,
remove
caps
from
all
secondary
conduit stubs
,
and
remove
covers
from
secondary openings
in
cubicle
floor
plates
.
The
arrangement
may
consist
of
a
single
complete
shipping
group
,
or
may
be
split
into
a
number
of
shipping
sections
for
a
long
lineup
.
Refer
to
the
general
arrangement
drawing
for
instructions
as
to
which
shipping
group
should be
installed
first
,
and
in
what
sequence
the
remaining
groups
are
to
be
installed
.
Move
the
first
group
into
position
as
shown
on
the
general
arrangement
drawing
.
5
.
The
switchgear
equipment
was
accurately aligned
at
the
factory
.
This
care
insures
proper
operation
and
fit
of
mating
parts
.
Supporting
surfaces for
the
switchgear
'
s
6
"
(
152
mm
)
base
must
be level and
in
the
same
plane
within
0.06
"
(
1.6
mm
)
.
If
concrete
,
grouted
channels
,
pier
supports
,
etc
.
,
do
not meet
this
requirement
,
or
if
there
is
any
projection higher
than the
support
points
in
line
with
the base
,
shims
must
be installed
in
the
following
manner
to
provide
an
equivalent
true
surface for
switchgear
support
.
Outdoor
switchgear
groups
which have been
assembled
on a
6
"
(
162
mm
)
base
must
be
supported
along
this base
with
a
span
between
support
points
not
exceeding
36
"
(
914
mm
)
.
If
shims
are
required
,
use
4
"
(
100
mm
)
square
strips placed
between the bottom
of
the base and the
founda
-
tion
,
in
the anchor bolt
area
where
they
will
be
clamped
firmly
in
place
.
Do
not
force
cubicle
in
firm
Anchoring
,
Leveling
,
and
Assembling
Indoor
Switchgear
Indoor
switchgear shipping
groups
are
held
in
true
alignment by
bolts
holding
the vertical sections
to
each
other
.
Figure
12
shows the location
of
the interunit
fasteners
used
to
attach sections
together
.
.
Figure
12
.
interim
it
Bolting
Locations
The entire
shipping
group
is
to
be anchored and leveled
as a
single
element without
loosening
any
hardware
until entire
shipping
group
is
leveled and anchored
.
1
.
The
switchgear
equipment
was
accurately
aligned
at
the
factory
.
This
care
insures
proper
operation
and
fit
of
mating
parts
.
Supporting
surfaces for
the
switchgear
at
each
anchoring
bolt locations
must
be level and
in
the
same
plane
within
0.06
"
(
1.6
mm
)
.
There
must not
be
any
projection
above this
plane
within
the
area
covered
by
the
switchgear
cubicles
.
If
purchaser
'
s
floor
or
grouted
sill channels do
not meet
this
requirement
,
it
will
be
necessary
to
shim
in
the
following
manner
.
The
six
(
6
)
anchor bolt
locations
in
each cubicle
must
freely
rest
in
firm
contact
with
the
mounting
support
surfaces
.
There
must not
be
any
projection
or
obstruction
in
other
areas
which
may
distort the cubicle
.
Do
not
force
cubicles
in
firm
contact
by drawing
down
anchoring
bolts because such drastic
means
will
distort
the cubicles
.
Add
4
"
(
100
mm
)
square
shims
adjacent
to
anchor
bolts
until
firm
contact
is achieved
.
Check
each
anchor bolt location
,
six
(
6
)
per
cubicle
.
(
See
Figure
7
)
2
.
Tighten
anchor bolts
or
weld
to
sills
.
3
.
If
the
lineup
consists
of
multiple
groups
,
move
the
next
group
into
position
,
with
the
front
of
units
in
line and
tight against
the
adjacent
group
.
Do
not
bolt
groups
together
at
this time
.
Check
that the cubicles
are
in
firm
contact
with
the
foundation
at
each
cor
-
ner
and anchor
point
,
and that bolt holes
are
in
align
-
ment
.
Add
4
"
(
100
mm
)
square
shims
as
necessary
.
Tighten
the anchor
bolts
.
Now
,
bolt
groups
together
.
4
.
After
installation is
complete
,
the
lifting
bar
between
units
may
be removed and the
lift
bars
pushed
down
inside the units
.
Note
that bolts inside the units
which
clamp
the
lift
bars
in
place
must
be loose
to
allow
movement
of
the
lift
bar and
must
be
retight
-
ened
after
bar
has
been
lowered
.
14
