Corporate Phonebook: Directory Settings
3.8 Corporate Phonebook: Directory Settings
3.8.1 LDAP
The Lightweight Directory Access Protocol enables access to a directory server via an LDAP
client. Various personal information is stored there, e.g. the name, organisation and contact
data of persons working in an organisation. When the LDAP client has found a person’s data,
e. g. by looking up the surname, the user can call this person directly using the displayed num-
ber.
For connecting the phone’s LDAP client to a LDAP server, the required access data must be
configured. The parameters Server address and Server port specify the IP address and host-
name as well as the port used by the LDAP server. If the Authentication is not set to "Anony-
mous", the user must authenticate himself with the server by providing a User name and a cor-
responding Password. The user name is the string in the LDAP bind request, e. g.
"C=GB,O=SIEMENS COMM,OU=COM,L=NTH,CN=BAYLIS MICHAEL". The internal struc-
ture will depend on the specific corporate directory.
Data required
• Server address: IP address or hostname of the LDAP server.
• Server port: Port on which the LDAP server is listening for requests.
Default: 389.
• Authentication: Authentication method used for connecting to the LDAP server. value
range: "Anonymous", "Simple".
Default: "Anonymous".
• User name: User name used for authentication with the LDAP server in the LDAP bind re-
quest.
• Password: Password used for authentication with the LDAP server.
>
LDAP is available only on OpenStage 60/80 phones.
>
The OpenStage phone supports LDAPv3.
