Rails en
35
5.
Open the appliance door and attach the door seal.
6.
Note:When sliding the pane in, ensure that the
glossy side of the pane is on the outside and the
cut-outs on the left and right are at the top.
Slide the inner pane into the left- and right-hand re-
tainers .
7.
Push the inner pane upwards until it is in the left-
and right-hand retainers .
8.
Put the door cover into position and push down
on it until you hear it click into place.
9.
Open the appliance door fully.
10.
Close the locking levers on the left- and right-hand
hinges .
a The locking levers are closed. The appliance door is
secured and cannot be detached.
11.
Close the appliance door.
Note:Do not use the cooking compartment again until
the door panes have been correctly fitted.
Rails
23 Rails
To thoroughly clean the rails and the cooking compart-
ment, or to replace the rails, you can remove the rails.
23.1 Detaching the rails
WARNING‒Risk of burns!
The shelf supports get very hot
▶ Never touch the shelf supports when hot.
▶ Always allow the appliance to cool down.
▶ Keep children at a safe distance.
1.
Lift the rail forwards slightly and detach it .
2.
Pull the whole rail to the front and remove it.
3.
Clean the rail.
→"Cleaning products", Page27
23.2 Attaching the rails
Notes
¡ The rails only fit on the right or left.
¡ For both rails, ensure that the curved rods are at the
front.
