Specifications
Supply voltage
100 Vac –15 % ... 110 Vac +10 % 50/60 Hz ±6 %
220 Vac –15 % ... 240 Vac +10 % 50/60 Hz ±6 %
Internal fuse 6.3 A (slow)
External fuse Maximum 10 A (slow)
Weight – LFL 2.2 lb
Weight – Wiring base 0.25 lb
Power consumption 3.5 VA
Mounting orientation No restrictions
General
Terminal 1 Line Maximum 5 A total load
Terminal 2 Neutral N/A
Terminal 3 Alarm 1 A pilot duty
Terminals 4 to 5 Limit string N/A
Terminals 6 and 7 Combustion Air
Blower
Motor 4 FLA, 24 LRA or 1.6 A pilot duty
Terminals 8, 9, 10, 11 Damper actuator N/A
Terminals 12, 13, 14 Air flow interlock N/A
Terminal 16 Ignition transformer 4 A
Terminal 17 Pilot fuel valve Motor 4 FLA, 24 LRA or 1.6 A pilot duty
Terminal 18 Main fuel valve Motor 4 FLA, 24 LRA or 1.6 A pilot duty
Terminal 19 Main fuel valve Motor 4 FLA, 24 LRA or 1.6 A pilot duty
Terminal 20 Damper actuator N/A
Terminal ratings
110V
UL File: MH26134 Standard: UL372
CSA Certificate: 1370843 Standard: CAN/CSA-C22.2 No 199-M89
FM File: J.I. 3003560 Standard: FM7610
110V & 220V
CE File: CE-0085AP0001 Standard: DIN EN 298
FCC Compliant Part 15 Class B - Emissions
Approvals
Vibration 0.5G Environment
Operation temperature range -5...+140 °F < 95 % relative humidity
Storage temperature range -58...+140 °F < 95 % relative humidity
Condensation, formation of ice and ingress
of water are not permitted!
Environmental
ratings
4/12
Siemens Building Technologies HVAC Products
11.15.2004
