MICROPROCESSOR CONTROLLED SYSTEM
The control system is made of the Siemens LMV central unit that performs all the burner control functions and of the Siemens AZL local
programming unit that interfaces the system with the user.
Keys
1 Burner
2AZL2..
3 Air actuator
4 Fuel actuator
5LMV2..
User interface
The AZL2x.. display/programming unit is shown below:
3
4
1
2
5
2
Bild 1/0707
P
V
hmin
s%
VSD
ESC
nfo
AF
