Siemens LMV52 series User Manual

230/327
Building Technologies Basic Documentation LMV5... CC1P7550en
15 Technical data 22.05.2018
15.2 Loads on terminals, cable lengths and cross-
sectional areas
General data
Mains voltage AC 120 V
-15% / +10%
AC 230 V
-15% / +10%
∂ Perm. mains primary fuse (external) Max. 16 AT Max. 16 AT
∂ Unit fuse F1 (internal) 6,3 AT to
DIN EN 60127 2/5
6,3 AT to
DIN EN 60127 2/5
∂ Mains supply: The mains input current depends on the status of the unit
Under voltage
∂ Safety shutdown from operating
position at mains voltage
< AC 96 V < AC 186 V
∂ Restart on increase of mains
voltage
> AC 100 V > AC 188 V
Oil pump / magnetic clutch
(rated voltage)
∂ Rated current 1.6 A 2 A
∂ Power factor Cosι >0.4 Cosι >0.4
Pressure switch relief valve
(rated voltage)
∂ Rated current 0.5 A 0.5 A
∂ Power factor Cosι >0.4 Cosι >0.4
Status inputs (CFN): Status inputs (with the exception of the safety loop) of the contact
feedback network (CFN) are used for system supervision and require a mains-related
input voltage
∂ Input safety loop Refer to Loads on output terminals
∂ Input currents and input voltages
- UeMax
- UeMin
- IeMax
- IeMin
UN +10%
UN -15%
1.5 mA peak
0.7 mA peak
UN +10%
UN -15%
1.5 mA peak
0.7 mA peak
∂ Recommended contact material for
external signal sources (air pressure
switch, pressure switch-min,
pressure switch max, etc.)
Gold-plated silver contacts
∂ Transition / transient behavior /
bouncing
- Perm. bounce time of contacts
when switching on/off
Max. 50 ms
(after the bounce time, the contact must be
permanently closed or open)
∂ UN AC 120 V AC 230 V
∂ Voltage detection
- ON
- OFF
AC 90...132 V
< AC 40 V
AC 180...253 V
< AC 80 V
Loads on input terminals

Siemens LMV52 series Specifications

General

Brand	Siemens
Model	LMV52 series
Category	Control Unit
Language	English
