Siemens MICROMASTER User Manual

7. SPECIFICATIONS English
© Siemens plc 1997 G85139-H1750-U049-B
35
2
6/09/9
7
7. SPECIFICATIONS
230 V Single Phase MICROMASTER Inverters
Order No. (6SE92 ..) 10-7BA40 11-5BA40 12-1BA40 12-8BA40 13-6BA40 15-2BB40 16-8BB40 21-0BC40 21-3BC40
Inverter model MM12 MM25 MM37 MM55 MM75 MM110 MM150 MM220
MM300
c
Input voltage range 1 AC 230 V +/-15% 2 AC 208 V +/-10%
Motor output rating
a
(kW / hp)
0.12 /
1
/
6
0.25 /
1
/
3
0.37 /
1
/
2
0.55 /
3
/
4
0.75 / 1
1.1 / 1
1
/
2
1.5 / 2 2.2 / 3 3.0 / 4
Continuous output 350 VA 660 VA 920 VA 1.14 kVA 1.5 kVA 2.1 kVA 2.8 kVA 4.0 kVA 5.2 kVA
Output current (nom.)
a
0.75 A 1.5 A 2.1 A 2.6 A 3.5 A 4.8 A 6.6 A 9.0 A 11.8 A
Output current (max. continuous) 0.8 A 1.7 A 2.3 A 3.0 A 3.9 A 5.5 A 7.4 A 10.4 A 13.6 A
Input current (I rms) 1.8 A 3.2 A 4.6 A 6.2 A 8.2 A 11.0 A 14.4 A 20.2 A 28.3 A
Recommended mains fuse 10 A 16 A 20 A 25 A 32 A
Recommended lead Input 1.0 mm
2
1.5 mm
2
2.5 mm
2
4.0 mm
2
cross-section (min.)
Output 1.0 mm
2
1.5 mm
2
2.5 mm
2
Dimensions (mm) (w x h x d) 73 x 175 x 141 149 x 184 x 172 185 x 215 x 195
Weight (kg / lb) 0.85 / 1.9 2.6 / 5.7 5.0 / 11.0
All 1 AC 230 V MICROMASTERS include integrated Class A filters. Optional external Class B filters are available (see section 8.3).
230 V 3 Phase MICROMASTER Inverters
Order No. (6SE92 ..) 10-7CA40 11-5CA40 12-1CA40 12-8CA40 13-6CA40 15-2CB40 16-8CB40 21-0CC40 21-3CC40 21-8CC13
Inverter model MM12/2 MM25/2 MM37/2 MM55/2 MM75/2 MM110/2 MM150/2 MM220/2
MM300/2
c
MM400/2
Input voltage range 1 - 3 AC 230 V +/-15% 3 AC
Motor output rating
a
(kW / hp)
0.12 /
1
/
6
0.25 /
1
/
3
0.37 /
1
/
2
0.55 /
3
/
4
0.75 / 1
1.1 / 1
1
/
2
1.5 / 2 2.2 / 3 3.0 / 4 4.0 / 5
Continuous output 350 VA 660 VA 920 VA 1.14 kVA 1.5 kVA 2.1 kVA 2.8 kVA 4.0 kVA 5.2 kVA 7.0 kVA
Output current (nom.)
a
0.75 A 1.5 A 2.1 A 2.6 A 3.5 A 4.8 A 6.4A 9.0 A 11.8 A 15.9 A
Output current (max. continuous) 0.8 A 1.7 A 2.3 A 3.0 A 3.9 A 5.5 A 7.0 A 10.4 A 13.6 A 17.5 A
Input current (I rms) (1 AC / 3 AC) 1.8 / 1.1 A 3.2 / 1.9 A 4.6 / 2.7 A 6.2 / 3.6 A 8.2 / 4.7 A 11.0 / 6.4 A 14.4 / 8.3 A 20.2 / 11.7 A 28.3 / 16.3 A - / 21.1 A
Recommended mains fuse
b
10 A 16 A 20 A 25 A
Recommended lead Input 1.0 mm
2
1.5 mm
2
2.5 mm
2
4.0 mm
2
cross-section (min.)
Output 1.0 mm
2
1.5 mm
2
2.5 mm
2
Dimensions (mm) (w x h x d) 73 x 175 x 141 149 x 184 x 172 185 x 215 x 195
Weight (kg / lb) 0.75 / 1.7 2.4 / 5.3 4.8 / 10.5
All 1 AC and 3 AC 230 V MICROMASTERS (excluding MM400/2) are suitable for 208 V operation.
All 3 AC 230 V MICROMASTERS can operate on 1 AC 230 V (MM300/2 requires an external line choke, e.g. 4EM6100-3CB).
380 V - 500 V Three Phase MICROMASTER Inverters
Order No. (6SE92 ..) 11-1DA40 11-4DA40 12-0DA40 12-7DA40 14-0DA40 15-8DB40 17-3DB40 21-0DC40 21-3DC40 21-5DC40
Inverter model MM37/3 MM55/3 MM75/3 MM110/3 MM150/3 MM220/3 MM300/3 MM400/3 MM550/3 MM750/3
Input voltage range 3 AC 380 V - 500 V +/-10%
Motor output rating
a
(kW / hp)
0.37 /
1
/
2
0.55 /
3
/
4
0.75 / 1
1.1 / 1
1
/
2
1.5 / 2 2.2 / 3 3.0 / 4 4.0 / 5
5.5 / 7
1
/
2
7.5 / 10
Continuous output 930 VA 1.15 kVA 1.5 kVA 2.1 kVA 2.8 kVA 4.0 kVA 5.2 kVA 7.0 kVA 9.0 kVA 12.0 kVA
Output current (nom.) (400 V / 500 V)
a
1.05/0.95A 1.5 / 1.3 A 2.0 / 1.8 A 2.8 / 2.5 A 3.7 / 3.3 A 5.2 / 4.6 A 6.8 / 6.0 A 9.2 / 8.1 A 11.8 / 10.4 A 15.8 / 13.9 A
Output current (max. continuous) 1.2/ 1.06 A 1.6 /1.45 A 2.1 / 1.9 A 3.0 / 2.7 A 4.0 / 3.6 A 5.9 / 5.3 A 7.7 / 6.9 A 10.2 / 9.1A 13.2/ 11.8 A 17.0 / 15.2 A
Input current (I rms) 2.2 A 2.8 A 3.7 A 4.9 A 5.9 A 8.8 A 11.1 A 13.6 A 17.1 A 22.1 A
Recommended mains fuse 10 A 16 A 20 A 25 A
Recommended lead Input 1.0 mm
2
1.5 mm
2
2.5 mm
2
4.0 mm
2
cross-section (min.)
Output 1.0 mm
2
1.5 mm
2
2.5 mm
2
Dimensions (mm) (w x h x d) 73 x 175 x 141 149 x 184 x 172 185 x 215 x 195
Weight (kg / lb) 0.75 / 1.7 2.4 / 5.3 4.8 / 10.5
Optional external Class A and Class B filters are available (see section 8.3).
Notes
a
Siemens 4 pole-motor, 1LA5 series or equivalent.
b
Assumes 3-phase supply. If a single phase supply is used, the input current ratings, wire sizes and fuses for single phase
MICROMASTERS will apply.
c
MM300 and MM300/2 require an external choke (e.g. 4EM6100-3CB) and a 30 A mains fuse to operate on a single phase supply.
