Milltronics Test Chain
22 Operating Instructions, 10/2021, A5E32310082-AB
Technical specifications
8
8.1 Test chain
Test chains
Medium conditions
Max. ambient temperature
65 °C (150 °F)
Design
Width between adjacent rolls
Single roll
4" (10 cm)
Double roll
6" (15 cm)
Belt loading to meet any application
5 lb/ft (7.4 kg/m) … 100 lb/ft (148.8 kg/m)
Material
Chain rollers
Oiled bronze bushings
Side plates
C1018 and C1020 cold rolled steel
Pins
C1018 and C1020 cold rolled steel
End shackles
C1018 and C1020 cold rolled steel
Fitted with eye links for attachment of wire rope
Fixed to brass plate bearing the calibrated weight in lb/ft or kg/m
Rollers
C1010 hot rolled steel
Roll bars/Cotter
pins
304 stainless steel
Connection links
Retained by stainless steel roll bars
Chain
Sprayed with rust inhibitor
a)
Approvals
CE, UKCA, RCM
a)
Nickel plated chains are available on special request.
