Siemens milltronics User Manual

Installing/Mounting
5.5 Standard motorized test chain storage reel
Milltronics Test Chain
Operating Instructions, 10/2021, A5E32310082-AB
13
5.5 Standard motorized test chain storage reel
View "A-A"
①
"D" dimension to center line of belt scale
⑥
To suit
②
reel Ø
⑦
"B"
③
View "A"
⑧
Gusset (by customer)
④
"E"
⑨
Eyebolt for chain restraint
⑤
Belt travel direction
reel Ø
"B"
"E"
36" (91.5 cm)
20.5" (52 cm)
13.25" (34 cm)
42" (107 cm)
23.5" (60 cm)
13.25" (34 cm)
48" (122 cm)
26.5" (67 cm)
13.25" (34 cm)
60" (152 cm)
32.5" (83 cm)
17.75" (45 cm)
Reels may have from one to two chain compartments (widths vary according to the width of
the specific test chain).
