Connection of the Supply Voltage
PowerLink 100
[sc_consuv, 1, --_--]
Figure 4-2 Connection of the supply voltage for PowerLink 100
PowerLink 50
[PL50-ps-connection, 1, --_--]
Figure 4-3 Connection of the supply voltage for PowerLink 50
General
The AC supply voltage is connected to the terminals PE-N-L1.
In case of DC voltage the (-) is connected to the N and (+) to the L1 terminal.
The terminals are covered.
4.2
Connecting the Device
4.2 Connection of the Supply Voltage
Smart Communications, PowerLink 100 and PowerLink 50, Product Information 35
E50405-U53-X-B3-7670, Edition 11.2014
