Siemens PXC Compact Series User Manual

Hardware Features
Compact Series Specifications
31 |
100
Siemens Industry, Inc.
Technical Reference Manual
145-172
Building Technologies
Restricted
2018-09-25
Electrical
Digital Output
Dedicated Points
PXC
- 16: Points 14-
16
PXC
- 24: Points 20-
24
PXC
- 36: Points 29-
36
Class 1 Relay
Form-C (NO and NC contacts)
125 Vac, 4A
250 Vac, 2A
Configurable Points
using an external relay
PXC-24:
Points 13-
16
PXC-36:
Points 1-
6
0 to 24 Vdc, 22 mA max.
Analog Output
Dedicated Points
PXC-16:
Points 9-
11
PXC-24:
Points 17-
19
0 to 10 Vdc @ 1 mA max.
Resolution: 11 mV
Initial Accuracy: ±2% of full range (32°F to 122°F
(0°C to 50°C) ambient)
Analog Output
Configurable Points, 0 to 10 Vdc
PXC-16:
Points 4-
8
PXC
- 24: Points 4-
16
PXC-36:
Points 1-
24
0 to 10 Vdc @ 1 mA max.
Resolution: 11 mV
Initial Accuracy: ±2% of full range (32°F to 122°F
(0°C to 50°C) ambient)
Configurable Points, 0 to 20 mA
PXC-24: Points 13-
16
PXC-36:
Points 1-
6
0 to 20 mA @ 650 Ω max.
Resolution: 22 µA
Initial Accuracy: ±2% of full range (32°F to 122°F
(0°C to 50°C) ambient)
Analog Input
Configurable Points
PXC - 16: Points 1-
8
PXC
- 24: Points 1-
16
PXC
- 36: Points 1-
24
Voltage (0-10 Vdc) Resolution: 2.2 mV
Current (4-20 mA) Resolution: 4.4 µA
1K Ni RTD @ 32°F (Siemens, JCI, DIN Ni 1K) Resolution: 0.05 C
1K Pt RTD (375 or 385 alpha) @ 32°F Resolution: 0.08 C (375), 0.13 C (385)
10K NTC Type 2 or Type 3 Thermistor Resolution: 0.02 C to 0.10 C
100K NTC Type 2 Thermistor Resolution: 0.14 C to 0.02 C
