Siemens PXC Compact Series

Hardware Features
PXC Compact on P1
60
| 100
Siemens Industry, Inc.
Technical Reference Manual
145-172
Building Technologies
Restricted
2018-09-25
Point Database for Application 3916
PXC Compact Point Database for Application 3916
Point Type
Point
Number
Descriptor
Factory
Default
(SI Units)
Engr Units
(SI Units)
Slope
(SI Units)
Intercept (SI
Units)
On Text
Off Text
LAI {01} ADDRESS 99 -- 1 0 -- --
LAO {02} APPLICATION 3916 -- 1 0 -- --
LAI {05} BATT 0 -- 1 0 -- --
LAI {06} BATT2 0 -- 1 0 -- --
LAO {08} P1 TIMEOUT 1 MIN 1 0 -- --
LAO {10} YEAR 2002 -- 1 0 -- --
LAO {11} MONTH 1 -- 1 0 -- --
LAO {12} DAY 1 -- 1 0 -- --
LAO {13} HOUR 0 -- 1 0 -- --
LAO {14} MINUTE 0 -- 1 0 -- --
LAO {15} SYNC HOUR 2 -- 1 0 -- --
LDO {16} SYNC NOW NO -- -- -- YES NO
LAO {20} OVRD TIME 0 HRS 1 0 -- --
LDO {29} DAY.NGT DAY -- -- -- NIGHT DAY
LAI {31} UI1 0.0 MA 0.001 -5.0 -- --
LAI {32} UI2 0.0 MA 0.001 -5.0 -- --
LAI {33} UI3 0.0 MA 0.001 -5.0 -- --
LAI {34} U4 0.0 VDC 0.001 -5.0 -- --
LAI {35} U5 0.0 VDC 0.001 -5.0 -- --
LAI {36} U6 0.0 VDC 0.001 -5.0 -- --
LAI {37} U7 0.0
DEG F
(DEG C)
0.05 -100.0 -- --
LAI {38} U8 0.0
DEG F
(DEG C)
0.05 -100.0 -- --
LAO {39} AO9 0.0 VDC 0.001 -5.0 -- --
LAO {40} AO10 0.0 VDC 0.001 -5.0 -- --
LAO {41} AO11 0.0 VDC 0.001 -5.0 -- --
LAI {42} DI12 OFF -- -- -- ON OFF
LAI {43} DI13 OFF -- -- -- ON OFF
LDO {44} DO14 OFF -- -- -- ON OFF
LDO {45} DO15 OFF -- -- -- ON OFF
LDO {46} DO16 OFF -- -- -- ON OFF
