Siemens PXC Compact Series

Hardware Features
PXM10S/T Product Overview and Description
74
| 100
Siemens Industry, Inc.
Technical Reference Manual
145-172
Building Technologies
Restricted
2018-09-25
Menu/Submenu
Step
Description
Main Rotate
DIAL
to highlight
Logoff
.
Press
DIAL
/
OK
to and select
Logoff
.
Displays the Logoff submenu.
Confirm Logoff
Are you sure?
Rotate
DIAL
to highlight
Yes
or
No
.
Press
DIAL
/
OK
to make
selection.
Confirms logoff and returns to splash screen.
NOTE:
If you press
ESC
, you are prompted with the same
Confirm Logoff screen.
Figure 13: Confirm Logoff Submenu
Navigation Menu
Menu Overview
● Push DIAL scrolls vertically and press button select - OK
● ESC key returns to last bookmark/page or previous character location when
inputting values
● INFO key activates additional information screen
● ALARM key activates unacknowledged alarm screen
● Main menu - alarms, display, monitor, settings, and logoff
