Siemens Switzerland Ltd User manual RVS61.843 CE1U2355en_02
HVAC Products 5 Handling 23. November 2007
Operating line operating
level
Function Default value Minimum Max Unit
None ¦ Electrical utility lock E6 ¦ Low-tariff E5 ¦
Compressor 2 overload E12 ¦ Source overload E14 ¦
Pressure switch source E26 ¦ Flow switch source E15 ¦
Flow switch consumers E24 ¦ Manual defrost E17 ¦
Common fault HP E20 ¦ Fault soft starter E25
5982 I Function input EX2
None ¦ Electrical utility lock E6 ¦ Low-tariff E5 ¦
Compressor 2 overload E12 ¦ Source overload E14 ¦
Pressure switch source E26 ¦ Flow switch source E15 ¦
Flow switch consumers E24 ¦ Manual defrost E17 ¦
Common fault HP E20 ¦ Fault soft starter E25
Low-tariff
-
5984 I
Function input EX3
None ¦ Electrical utility lock E6 ¦ Low-tariff E5 ¦
Compressor 2 overload E12 ¦ Source overload E14 ¦
Pressure switch source E26 ¦ Flow switch source E15 ¦
Flow switch consumers E24 ¦ Manual defrost E17 ¦
Common fault HP E20 ¦ Fault soft starter E25
Source overload E14
-
5986 I
Function input EX4
None ¦ Electrical utility lock E6 ¦ Low-tariff E5 ¦
Compressor 2 overload E12 ¦ Source overload E14 ¦
Pressure switch source E26 ¦ Flow switch source E15 ¦
Flow switch consumers E24 ¦ Manual defrost E17 ¦
Common fault HP E20 ¦ Fault soft starter E25
Pressure switch source
E26
-
5988 I
Function input EX5
None ¦ Electrical utility lock E6 ¦ Low-tariff E5 ¦
Compressor 2 overload E12 ¦ Source overload E14 ¦
Pressure switch source E26 ¦ Flow switch source E15 ¦
Flow switch consumers E24 ¦ Manual defrost E17 ¦
Common fault HP E20 ¦ Fault soft starter E25 ¦ 3-phase
current
Flow switch source E15
-
5990 I
Function input EX6
None ¦ Electrical utility lock E6 ¦ Low-tariff E5 ¦ Comp-
ressor 2 overload E12 ¦ Source overload E14 ¦ Pressure
switch source E26 ¦ Flow switch source E15 ¦ Flow switch
consumers E24 ¦ Manual defrost E17 ¦ Common fault HP
E20 ¦ Fault soft starter E25 ¦ 3-phase current
Flow switch consumers
E24
-
5992 I
Function input EX7
None ¦ Electrical utility lock E6 ¦ Low-tariff E5 ¦ Comp-
ressor 2 overload E12 ¦ Source overload E14 ¦ Pressure
switch source E26 ¦ Flow switch source E15 ¦ Flow switch
consumers E24 ¦ Manual defrost E17 ¦ Common fault HP
E20 ¦ Fault soft starter E25 ¦ 3-phase current
None
-
6014 I
Function mixing group 1
None ¦ Heating circ/cooling circ 1 ¦ Cooling circuit 1 ¦
Heating circ/cooling circ 1 ¦ Prim contr/system pump ¦
DHW primary controller ¦ Instantaneous DHW heater
Heating circuit 1 -
6020 I Function extension module 1
None ¦ Multifunctional ¦ Cooling circuit 1 ¦ Cooling circuit 2
¦ Solar DHW ¦ Prim contr/system pump ¦ DHW primary
controller ¦ Instantaneous DHW heater
None
-
6021 I Function extension module 2
None ¦ Multifunctional ¦ Cooling circuit 1 ¦ Cooling circuit 2
¦ Solar DHW ¦ Prim contr/system pump ¦ DHW primary
controller ¦ Instantaneous DHW heater
None
-
6030 I
Relay output QX21
None ¦ El imm heater 1 flow K25 ¦ El imm heater 2 flow
K26 ¦ Div valve cool source Y28 ¦ System pump Q14 ¦
Cascade pump Q25 ¦ Heat gen shutoff valve Y4 ¦ El imm
heater DHW K6 ¦ Circulating pump Q4 ¦ St tank transfer
pump Q11 ¦ DHW intern circ pump Q33 ¦ DHW mixing
pump Q35 ¦ Collector pump Q5 ¦ Collector pump 2 Q16 ¦
Solar pump ext exch K9 ¦ Solar ctrl elem buffer K8 ¦ Solar
ctrl elem swi pool K18 ¦ El imm heater buffer K16 ¦ H1
None -
