Siemens QAA55.110 User Manual

58/221
Siemens Switzerland Ltd User manual RVS61.843 CE1U2355en_02
HVAC Products 5 Handling 23. November 2007
Operating line operating
level
Function Default value Minimum Max Unit
pump Q15 ¦ H2 pump Q18 ¦ H3 pump Q19 ¦ Heat circuit
pump HCP Q20 ¦ 2nd pump speed HC1 Q21 ¦ 2nd pump
speed HC2 Q22 ¦ 2nd pump speed HCP Q23 ¦ Diverting
valve cooling Y21 ¦ Air dehumidifier K29 ¦ Heat request
K27 ¦ Refrigeration request K28 ¦ Alarm output K10 ¦
Time program 5 K13
6031 I
Relay output QX22
None ¦ El imm heater 1 flow K25 ¦ El imm heater 2 flow
K26 ¦ Div valve cool source Y28 ¦ System pump Q14 ¦
Cascade pump Q25 ¦ Heat gen shutoff valve Y4 ¦ El imm
heater DHW K6 ¦ Circulating pump Q4 ¦ St tank transfer
pump Q11 ¦ DHW intern circ pump Q33 ¦ DHW mixing
pump Q35 ¦ Collector pump Q5 ¦ Collector pump 2 Q16 ¦
Solar pump ext exch K9 ¦ Solar ctrl elem buffer K8 ¦ Solar
ctrl elem swi pool K18 ¦ El imm heater buffer K16 ¦ H1
pump Q15 ¦ H2 pump Q18 ¦ H3 pump Q19 ¦ Heat circuit
pump HCP Q20 ¦ 2nd pump speed HC1 Q21 ¦ 2nd pump
speed HC2 Q22 ¦ 2nd pump speed HCP Q23 ¦ Diverting
valve cooling Y21 ¦ Air dehumidifier K29 ¦ Heat request
K27 ¦ Refrigeration request K28 ¦ Alarm output K10 ¦
Time program 5 K13
None -
6032 I
Relay output QX23
None ¦ El imm heater 1 flow K25 ¦ El imm heater 2 flow
K26 ¦ Div valve cool source Y28 ¦ System pump Q14 ¦
Cascade pump Q25 ¦ Heat gen shutoff valve Y4 ¦ El imm
heater DHW K6 ¦ Circulating pump Q4 ¦ St tank transfer
pump Q11 ¦ DHW intern circ pump Q33 ¦ DHW mixing
pump Q35 ¦ Collector pump Q5 ¦ Collector pump 2 Q16 ¦
Solar pump ext exch K9 ¦ Solar ctrl elem buffer K8 ¦ Solar
ctrl elem swi pool K18 ¦ El imm heater buffer K16 ¦ H1
pump Q15 ¦ H2 pump Q18 ¦ H3 pump Q19 ¦ Heat circuit
pump HCP Q20 ¦ 2nd pump speed HC1 Q21 ¦ 2nd pump
speed HC2 Q22 ¦ 2nd pump speed HCP Q23 ¦ Diverting
valve cooling Y21 ¦ Air dehumidifier K29 ¦ Heat request
K27 ¦ Refrigeration request K28 ¦ Alarm output K10 ¦
Time program 5 K13
None -
6040 I
Sensor input BX21
None ¦ Buffer sensor B4 ¦ Buffer sensor B41 ¦ Collector
sensor B6 ¦ DHW sensor B31 ¦ Hot-gas sensor B82 ¦
Refrig sensor liquid B83 ¦ DHW charging sensor B36 ¦
DHW outlet sensor B38 ¦ DHW circulation sensor B39 ¦
Swimming pool sensor B13 ¦ Collector sensor 2 B61 ¦
Solar flow sensor B63 ¦ Solar return sensor B64 ¦ Buffer
sensor B42 ¦ Common flow sensor B10 ¦ Cascade return
sensor B70¦Special temp sensor 1¦Special temp sensor 2
None -
6041 I
Sensor input BX21
None ¦ Buffer sensor B4 ¦ Buffer sensor B41 ¦ Collector
sensor B6 ¦ DHW sensor B31 ¦ Hot-gas sensor B82 ¦
Refrig sensor liquid B83 ¦ DHW charging sensor B36 ¦
DHW outlet sensor B38 ¦ DHW circulation sensor B39 ¦
Swimming pool sensor B13 ¦ Collector sensor 2 B61 ¦
Solar flow sensor B63 ¦ Solar return sensor B64 ¦ Buffer
sensor B42 ¦ Common flow sensor B10 ¦ Cascade return
sensor B70¦Special temp sensor 1¦Special temp sensor 2
None -
6046 I Function of input H2
None ¦ Optg mode change HCs+DHW ¦ Optg mode
changeover HCs ¦ Optg mode changeover HC1 ¦ Optg
mode changeover HC2 ¦ Optg mode changeover HCP ¦
Error/alarm message ¦ Min flow temp setpoint ¦ Heat
request 10V ¦ Dewpoint monitor ¦ Flow temp setp incr
hygro ¦ Refrigeration request ¦ Refrigeration request 10V ¦
Pressure measurement 10V ¦ Rel room humidity 10V ¦
Room temp 10V ¦ Release swimming pool ¦ Swi-on
command HP stage 1 ¦ Swi-on command HP stage 2
Optg mode change HCs+DHW
-
