59/221
Siemens Switzerland Ltd User manual RVS61.843 CE1U2355en_02
HVAC Products 5 Handling 23. November 2007
Operating
line
operating
Function
Default value
Minimum
Max
Unit
6047 I Contact type H2
NC ¦ NO
NO
-
6048 I Function value, contact H2 30 0 130 °C
6049 I
Voltage value 1 H2
0 0 10 V
6050 I
Function value 1 H2
0 -100 500 -
6051 I
Voltage value 2 H2
10 0 10 V
6052 I
Function value 2 H2
10 -100 500 -
6070 I Function output UX
None ¦ Source pump Q8/fan K19 ¦ DHW pump Q3 ¦ DHW
intern circ pump Q33 ¦ Instant DHW heater Q34 ¦
Collector pump Q5 ¦ Collector pump 2 Q16 ¦ Solar pump
buffer K8 ¦ Solar pump ext exch K9 ¦ Solar pump swi pool
K18 ¦ Heat circ pump HC1 Q2 ¦ Heat circ pump HC2 Q6 ¦
Heat circ pump HCP Q20 ¦ HP setpoint ¦ Output request ¦
Heat request ¦ Refrigeration request ¦ HP modulating
None
-
6071 I Signal logic output UX
Standard ¦ Inverted
Standard -
6072 I
Signal output UX
0..10V ¦ PWM
0..10V -
6075 I Temperature value 10V UX 100 5 130 °C
6097 F Sensor type collector
NTC* ¦ Pt 1000
1 1 2 -
6098 F Readjustm collector sensor 0 -20 20 °C
6099 F Readjustm coll sensor 2 0 -20 20 °C
6100 F Readjustm outside sensor 0.0 -3.0 3.0 °C
6110 F Time constant building 20 0 50 h
6120 F Frost protection plant
Off ¦ On
On
-
6135 F Air dehumidifier
Off ¦ On
Off
-
6136 F
Release air dehumidifier
24h/day ¦ Time progr. heating circuit ¦ Time program 5
24h/day -
6137 F
Air dehumidifier r.h. on
55 0 100 %
6138 F
Air dehumidifier r.h. SD
5 2 50 %
6200 F
Save sensors
No ¦ Yes
No -
6201 F
Reset sensors
No ¦ Yes
No -
6204 F
Save parameters
No ¦ Yes
No -
6205 F Reset to default parameters
No ¦ Yes
No -
6212 I
Check no. heat source 1
- 0 199999 -
6213 I
Check no. heat source 2
- 0 199999 -
6215 I
Check no. storage tank
- 0 199999 -
6217 I
Check no. heating circuits
- 0 199999 -
6220 I Software version - 0 99.9 -
LPB system
6600 I
Device address
1 0 16 -
6601 F Segment address 0 0 14 -
6604 F Bus power supply function
Off ¦ Automatically
Automatic -
