61/221
Siemens Switzerland Ltd User manual RVS61.843 CE1U2355en_02
HVAC Products 5 Handling 23. November 2007
Operating
line
operating
Function
Default value
Minimum
Max
Unit
7075 I Cur starts compr2/hrs run 0 0 12.0 -
7076 I Diff condens max/week − − − − − − / 1 250 -
7077 I Cur diff condens max/week 0 0 250 -
7078 I Diff condens min/week − − − − − − / 1 250 -
7079 I Cur diff condens min/week 0 0 250 -
7080 I Diff evap max/week − − − − − − / 1 250 -
7081 I Cur diff evap max/week 0 0 250 -
7082 I Diff evap min/week − − − − − − / 1 250 -
7083 I Cur diff evap min/week 0 0 250 -
7090 I DHW storage tank interval − − − − − − / 1 240 months
7091 I DHW stor tank since maint 0 0 240 months
7092 I DHW charg temp HP min 40 8 80 °C
7093 I Curr DHW charg temp HP - 8 80 °C
7119 F Economy function
Locked ¦ Released
Locked -
7120 E Economy mode
Off ¦ On
Off
-
7141 E
Emergency operation
Off ¦ On
Off
-
7142 F Emergency op function type
Manually ¦ Automatically
Manually -
7150 I Simulation outside temp − − − − − − / -50 50 °C
7152 I
Triggering defrost
No ¦ Yes
No -
7160 F Reset limitation
No ¦ Yes
No -
7181 I Phone no. responsibility 1 0 16 digits
7183 I Phone no. responsibility 2 0 16 digits
Input / output test
7700 I Relay test
No test ¦ Everything off ¦ Source pump Q8/fan K19 ¦
Compressor 1 K1 ¦ Condenser pump Q9 ¦ DHW pump Q3
¦ Heating circuit pump Q2¦ Heat circ mix valve op Y1¦
Heat circ mix valve cl Y2 ¦ Relay output QX23 module 1 ¦
Relay output QX21 module 1 ¦ Relay output QX22
module 1 ¦ Relay output QX1 ¦ Relay output QX2 ¦ Relay
output QX3 ¦ Relay output QX4 ¦ Relay output QX5 ¦
Relay output QX6 ¦ Relay output QX23 module 2 ¦ Relay
output QX21 module 2 ¦ Relay output QX22 module 2
No test -
7710 I Output test UX − − − − − − / 0 100 %
7711 I Voltage signal UX - 0.0 10.0 Volt
7714 I
PWM signal P1
- 0 100 %
7730 I Outside temp B9 - -50.0 50.0 °C
7732 I Flow temp B1 - 0.0 140.0 °C
7750 I DHW temp B3 - 0.0 140.0 °C
7770 I
Flow temp HP B21
- 0.0 140.0 °C
7771 I
Return temp HP B71
- 0.0 140.0 °C
7772 I
Hot-gas temp B81
- 0.0 180.0 °C
7775 I Source inlet temp B91 - -50.0 50.0 °C
7777 I
Sensor temp B92, B84
- -50.0 50.0 °C
7820 I
Sensor temp BX1
- -28 350 °C
7821 I
Sensor temp BX2
- -28 350 °C
