Siemens Switzerland Ltd User manual RVS61.843 CE1U2355en_02
HVAC Products 5 Handling 23. November 2007
Operating line operating
level
Function Default value Minimum Max Unit
7822 I
Sensor temp BX3
- -28 350 °C
7823 I
Sensor temp BX4
- -28 350 °C
7824 I
Sensor temp BX3
- -28 350 °C
7830 I Sensor temp BX21 module 1 - -28 350 °C
7831 I Sensor temp BX22 module 1 - -28 350 °C
7832 I Sensor temp BX21 module 2 - -28 350 °C
7833 I Sensor temp BX22 module 2 - -28 350 °C
7840 I Voltage signal H1 - 0.0 10.0 Volt
7841 I Contact state H1
Open ¦ Closed
- 0 1 -
7845 I Voltage signal H2 - 0.0 10.0 Volt
7846 I Contact state H2
Open ¦ Closed
- 0 1 -
7854 I Voltage signal H3 - 0.0 10.0 Volt
7855 I Contact state H3
Open ¦ Closed
- 0 1 -
7889 I Low-pressure switch E9
0V ¦ 230V
- 0 1 -
7890 I High-pressure switch E10
0V ¦ 230V
- 0 1 -
7891 I
Compressor 1 overload E11
0V ¦ 230V
- 0 1 -
7911 I
Input EX1
0V ¦ 230V
- 0 1 -
7912 I Input EX2
0V ¦ 230V
- 0 1 -
7913 I
Input EX3
0V ¦ 230V
- 0 1 -
7914 I
Input EX4
0V ¦ 230V
- 0 1 -
7915 I
Input EX5
0V ¦ 230V
- 0 1 -
7916 I
Input EX6
0V ¦ 230V
- 0 1 -
7917 I
Input EX7
0V ¦ 230V
- 0 1 -
State
8000 I State heating circuit 1 - 0 255 -
8001 I
State heating circuit 2
- 0 255 -
8002 I State heating circuit P - 0 255 -
8003 I
State DHW
- 0 255 -
8004 I
State cooling circuit 1
- 0 255 -
8006 I State heat pump - 0 255 -
8007 I
State solar
- 0 255 -
8010 I
State buffer
- 0 255 -
8011 I State swimming pool - 0 255 -
8050 I
History 1
-
8051 I
State code 1
- 0 255 -
8052 I
History 2
-
8053 I
State code 2
- 0 255 -
8054 I
History 3
-
8055 I
State code 3
- 0 255 -
