Siemens Switzerland Ltd User manual RVS61.843 CE1U2355en_02
HVAC Products 5 Handling 23. November 2007
Operating line operating
level
Function Default value Minimum Max Unit
8056 I
History 4
-
8057 I
State code 4
- 0 255 -
8058 I
History 5
-
8059 I
State code 5
- 0 255 -
8060 I
History 6
-
8061 I
State code 6
- 0 255 -
8062 I
History 7
-
8063 I
State code 7
- 0 255 -
8064 I
History 8
-
8065 I
State code 8
- 0 255 -
8066 I
History 9
-
8067 I
State code 9
- 0 255 -
8068 I
History 10
-
8069 I
State code 10
- 0 255 -
Diagnostics cascade
8100
to
8130
I Priority source 1…16 - 0 16
8101
to
8131
I State source 1...16
Missing ¦ Faulty ¦ Manual control active ¦ Heat generation
lock active ¦ Chimney sweep funct active ¦ Separate DHW
circuit active ¦ Ouside temp limit active ¦ Not released ¦
Released
Missing
8138 I Cascade flow temp - 0.0 140.0 °C
8139 I Cascade flow temp setp - 0.0 140.0 °C
8140 I Cascade return temp - 0.0 140.0 °C
8141 I Cascade return temp setp - 0.0 140.0 °C
8150 I Source seq ch’over current - 0 990 h
Diagnostics heat source
8400 I Compressor 1 K1
Off ¦ On
- 0 1 -
8401 I
Compressor 2 K2
Off ¦ On
-
0
1 -
8402 I
El imm heater 1 flow
Off ¦ On
- 0 1 -
8403 I
El imm heater 2 flow
Off ¦ On
- 0 1 -
8404 I Source pump Q8
Off ¦ On
- 0 1 -
8405 I
Speed of source pump
Off ¦ On
- 0 100 %
8406 I
Condenser pump Q9
Off ¦ On
- 0 1 -
8410 E Return temp HP - 0.0 140.0 °C
8411 E Setpoint HP - 0.0 140.0 °C
8412 E
Flow temp HP
- 0.0 140.0 °C
8413 E
Compressor modulation
- 0 100 %
8415 I
Hot-gas temp 1
- 0.0 180.0 °C
8416 F
Hot-gas temp max
- 0.0 180.0 °C
8417 I
Hot-gas temp 2
- 0.0 180.0 °C
8418 I
Hot-gas temp max
- 0.0 180.0 °C
8420 I
Refrig temp liquid
- 0.0 140.0 °C
8425 I
Temp diff condenser
- -50.0 140.0 °C
