65/221
Siemens Switzerland Ltd User manual RVS61.843 CE1U2355en_02
HVAC Products 5 Handling 23. November 2007
Operating
line
operating
Function
Default value
Minimum
Max
Unit
8548 I Collector temp 2 max -28 -28 350 °C
8549 I Collector temp 2 min 350 -28 350 °C
8550 I dT collector 2/DHW 0 -168 350 °C
8551 I dT collector 2/buffer 0 -168 350 °C
8552 I dt collector 2/swimming pool 0 -168 350 °C
Diagnostics consumers
8700 E
Outside temp
- -50.0 50.0 °C
8701 E Outside temp min - -50.0 50.0 °C
8702 E Outside temp max - -50.0 50.0 °C
8703 I Outside temp attenuated - -50.0 50.0 °C
8704 I
Outside temp composite
- -50.0 50.0 °C
8720 I
Rel room humidity
- 0 100 %
8721 I
Room temp
- 0 50 °C
8722 I
Dewpoint temp 1
- 0 50 °C
8730 I Heating circuit pump Q2
Off ¦ On
Off
-
8731 I
Heat circ mix valve op Y1
Off ¦ On
Off
-
8732 I Heat circ mix valve cl Y2
Off ¦ On
Off
-
8735 F Speed heating circuit pump 1 - 0 100 %
8740 E Room temp 1 - 0.0 50.0 °C
8741 E Room setpoint 1 20 4.0 35.0 °C
8743 E
Flow temp 1
- 0.0 140.0 °C
8744 E Flow temp setpoint 1 - 0.0 140.0 °C
8751 I Cooling circuit pump 1 - 0 1 -
8752 I
Cool circ mix valve 1 open
- 0 1 -
8753 I
Cool circ mix valve 1 closed
- 0 1 -
8754 I
Diverting valve cooling 1
- 0 1 -
8756 E
Flow temp cooling 1
- 0 140 °C
8757 E
Flow temp setp cooling 1
- 0 140 °C
8760 I Heating circuit pump Q6
Off ¦ On
Off. -
8761 I Heat circ mix valve op Y5
Off ¦ On
Off. -
8762 I Heat circ mix valve cl Y6
Off ¦ On
Off. -
8765 F Speed heating circuit pump 2 - 0 100 %
8770 E Room temp 2 - 0.0 50.0 °C
8771 E Room setpoint 2 20 4.0 35.0 °C
8773 E
Flow temp 2
- 0.0 140.0 °C
8774 E Flow temp setpoint 2 - 0.0 140.0 °C
8795 F Speed heating circuit pump B - 0 100 %
8800 E Room temp P - 0.0 50.0 °C
8801 E Room setpoint P 20 4.0 35.0 °C
8803 E Flow temp setpoint P - 0.0 140.0 °C
8820 I DHW pump Q3
Off ¦ On
Off
-
8821 I
El imm heater DHW K6
Off ¦ On
Off -
8825 F Speed DHW pump - 0 100 %
