Siemens QAA55.110 User Manual

66/221
Siemens Switzerland Ltd User manual RVS61.843 CE1U2355en_02
HVAC Products 5 Handling 23. November 2007
Operating line operating
level
Function Default value Minimum Max Unit
8826 F Speed DHW interm circ pump - 0 100 %
8827 F
Speed inst DHW heater pump
- 0 100 %
8830 E DHW temp 1 - 0.0 140.0 °C
8831 E DHW temp setpoint 55 8.0 80.0 °C
8832 I DHW temp 2 - 0.0 140.0 °C
8835 I DHW circulation temp - 0.0 140.0 °C
8836 I DHW charging temp - 0.0 140.0 °C
8840 F Hours run DHW pump 0:00:00 00:00:00 2730:15:00 h/Min/s
8841 F Start counter DHW pump 0 0 65535 -
8842 F Hours run el DHW
0:00:00 00:00:00 2730:15:00 h/Min/s
8843 F Start counter el DHW 0 0 65535 -
8850 I DHW primary controller temp 0 0 140.0 °C
8851 I DHW primary controller setp 0 0 140.0 °C
8852 I Instant DHW heater temp 0 0 140.0 °C
8853 I Instant DHW heater setpoint 0 0 140.0 °C
8900 I Swimming pool temp 0 0 140.0 °C
8901 I Swimming pool setpoint 24 8 80.0 °C
8930 I Primary controller temp 0 0 140.0 °C
8931 I Primary controller setpoint 0 0 140.0 °C
8950 I Common flow temp 0 0 140.0 °C
8951 I
Common flow temp setpoint
0 0 140.0 °C
8957 I
Common flow setp refrig
0 0 140.0 °C
8970 I
El imm heater buffer
Off ¦ On
Off -
8980 E Buffer temp 1 - 0.0 140.0 °C
8981 E Buffer setpoint - 0.0 140.0 °C
8982 E Buffer temp 2 - 0.0 140.0 °C
8983 I Buffer temp 3 - 0.0 140.0 °C
8990 F Hours run el buffer
0:00:00 00:00:00 2730:15:00 h/Min/s
8991 F Start counter el buffer 0 0 65535 -
9000 I
Flow temp setpoint H1
5 0.0 140.0 °C
9001 I Flow temp setpoint H2 5 0.0 140.0 °C
9004 I Flow temp setpoint H3 5 0.0 140.0 °C
9005 I Water pressure H1 0 -100 500 mbar
9006 I Water pressure H2 0 -100 500 mbar
9009 I Water pressure H3 0 -100 500 mbar
9031 E Relay output QX1
Off ¦ On
Off
-
9032 E Relay output QX2
Off ¦ On
Off
-
9033 E Relay output QX3
Off ¦ On
Off
-
9034 E Relay output QX4
Off ¦ On
Off
-
9035 E
Relay output QX5
Off ¦ On
Off
-
9036 E
Relay output QX6
Off ¦ On
Off
-
9050 I
Relay output QX21 module 1
Off ¦ On
Off
-
9051 I
Relay output QX22 module 1 Off
-
