2.1.5 Operator unit AVS37.390...
The AVS37.390 operator unit must be connected to terminal X30 of the basic unit
using the AVS82.491/109 connecting cable. The connectors are coded.
VA Visual area
AA Active area
A Control panel, front
The AVS37.39
0 operator unit is a PCB version without casing, supplied by
Siemens.
Connections
Dimensions
