67
Siemens Graphical User Interface UI400 CE1U2348en
Building Technologies 2014-06-03
Operate special functions
Special functions are required in special plant and service situations.
l The service/setting pages (
) are preselected in the navigation bar.
The workflow is explained using the example of floor curing special function:
1. Turn the control knob and select "Special operations".
2. Press the control knob.
'Special operations' opens. The title of the first special operations page is
preselected. The first special operation page indicates whether a special
operation is active.
3. Push the control knob to select the special operation page title.
4. Turn the control knob and go to the page "Floor curing zone 1".
5. Press and turn the control knob to change to the work area for the flooring
curing function.
The state of the floor curing function (off) is preselected.
6. Press the control knob to select state "off".
7. Press the control knob and select the desired floor curing function, e.g. function
heating.
8. Press the control knob to confirm selection.
In the work area, two additional operating lines are now displayed.
a The floor curing function is now activated, visible on the service special
operation symbol ( ) on the status bar.
Deactivate the floor curing function by setting the status for "Floor curing zone 1" to
"Off".
Prerequisites
Deactivate
