19 / 60
Siemens RDG100, RDG100T, RDG110, RDG140, RDG160 Basic Documentation CE1P3181en
Building Technologies Functions 28 May 2009
If parameter P68 (extend Comfort period) = 0, extended Comfort cannot be
activated; pressing the left button will show “OFF” (blinking 3 times)
The current operating mode can be forced temporarily into Comfort or Energy
Saving / Protection mode. The time period is adjusted via the rotary knob:
• Extend presence: Set the device to Comfort mode for the selected time period
• Extend absence: Set the device to Energy Saving / Protection mode for the
selected time period
To activate the function, keep the left button pressed and, within 3 seconds, turn
the rotary knob
• clockwise for extended presence
• counterclockwise for extended absence
The rotary knob adjusts the time period:
• Extend presence: 0.00…+9:30 in steps of 30 minutes; symbol
appears
• Extend absence: 0.00…–9:30 in steps of 30 minutes; symbol
or appears
During the extended presence / absence period, timer symbol
appears.
Function without time program
User operating mode
selection
Operating
mode when
activating
function
Function Operating mode
during function
Operating mode at
the end of function
Comf Extension Comf Prot
Comf Absence Prot Comf
Prot Not available - -
Comf Extension Comf Eco
Comf Absence Eco Comf
Eco Extension Comf Eco
Eco Absence Eco Comf
Prot Not available - -
Function with time program (RDG100T)
User operating mode
selection
Operating
mode when
activating
function
Function Operating mode
during function
Operating mode at
the end of function
Auto Extension Comf Auto
Auto Absence Prot Auto
Comf Extension Comf Auto
Comf Absence Prot Auto
Prot Not available - -
Eco Extension Comf Auto
Eco Absence Eco Auto
(
)
Prot Not available - -
Temporary timer for
extension of presence /
absence
