9 / 60
Siemens RDG100, RDG100T, RDG110, RDG140, RDG160 Basic Documentation CE1P3181en
Building Technologies Use 28 May 2009
2.4 Accessories
Description Product no.
Data
Sheet
Changeover mounting kit (50 pcs / package) ARG86.3 1840
Adapter plate 120 x 120 mm for 4“ x 4“ conduit
boxes
ARG70
Adapter plate 112 x 130 mm for surface wiring ARG70.2
2.5 Ordering
When ordering, please indicate product no. and description:
E.g. RDG100 room thermostat
Order the IRA211 infrared remote control separately.
Order valve actuators separately.
3 Use
The RDG1… room thermostats are designed for use with the following types of
system:
Fan coil units via ON/OFF or modulating control outputs:
• 2-pipe system
• 2-pipe system with electrical heater
• 2-pipe system and radiator / floor heating
• 4-pipe system
• 4-pipe system with electrical heater
• 2-stage heating or cooling system
Chilled / heated ceilings (or radiators) via ON/OFF or modulating control
outputs:
• Chilled / heated ceiling
• Chilled / heated ceiling with electrical heater
• Chilled / heated ceiling and radiator / floor heating
• Chilled / heated ceiling, 2-stage cooling or heating
Heat pumps with dx type equipment:
• 1-stage compressor for heating or cooling
• 1-stage compressor for heating or cooling with electrical heater
• 1-stage compressor for heating or cooling and radiator / floor heating
• 1-stage compressor for heating and cooling with reversing valve
• 2-stage compressor for heating or cooling
