46 / 60
Siemens RDG100…/RDG110…/RDG140.../RDG160… Basic Documentation CE1P3076.en
Building Technologies Functions 28 May 2009
4.15.1 Service level
Parameter
Name Factory setting Range
RDG100
RDG100T
RDG110
RDG140
RDG160
Service level
P01 Control sequence When 2-pipe /
2-stage:
1 = Cooling only
When 4-pipe:
4 = H and C
0 = Heating only
1 = Cooling only
2 = H/C changeover manual
3 = H/C changeover auto
4 = Heating and Cooling
P02 User operating mode profile (mode button) 1 1 = (Auto) - Comfort - Protection
2 = (Auto) - Comfort - E Saving - Prot
P03 User fan mode selection 0 0 = Auto - Manual
1 = Manual
2 = Auto - Manual - Prot
P04 Selection of °C or °F 0 (°C) 0 = Degrees Celsius (°C)
1 = Degrees Fahrenheit (°F)
P05 Sensor calibration (intern, extern) 0 K – 3 ... 3 K
P06 Standard temperature display 0 0 = Room Temperature
1 = Setpoint
P07 Display info line
(2nd line of LCD)
0 0 = --- (No display)
1 = °C and °F
0..1
0..1 0..1 0..1
P08 Comfort setpoint 21 °C 5 ... 40 °C
P09 Minimum setpoint in Comfort mode 5 °C 5 ... 40 °C
P10 Maximum setpoint in Comfort mode 35 °C 5 ... 40 °C
P11 Energy Saving heating setpoint 15 °C OFF, 5 ... WcoolE-saving;
(WcoolE-saving = 40 °C max)
P12 Energy Saving cooling setpoint 30 °C OFF, WHeatE-saving ... 40 °C;
(WHeatE-saving = 5 °C min)
P13 Electric reheater in cooling mode ON ON: Enabled
OFF: Disabled
P14 Button lock function 0 0 = Unlocked
1 = Auto locked
2 = Manual locked
Parameter available
Parameter not available
Parameter display depends on selected application and function
Note
