44 / 60
Siemens RDG100…/RDG110…/RDG140.../RDG160… Basic Documentation CE1P3076.en
Building Technologies Functions 28 May 2009
4.14 DIP switches
Use the DIP switches at the rear of the thermostat to commission the thermostat's
basic application prior to snapping it to the base.
– The application is set via DIP switches 1…3
– The function of the control outputs (2-position or 3-position) is set via DIP
switches 4 and 5 for RDG 100 and RDG100T.
For RDG140 and RDG160 (DC 0…10 V), DIP switches 4 and 5 serve to invert
the DC 0…10 V signal
For details concerning connection of peripheral devices and setting of the DIP
switches, refer to the Mounting Instructions:
– [4] M3181.1 (RDG100, RDG100T)
– [5] M3181.2 (RDG110)
– [6] M3181.3 (RDG140, RDG160)
During startup, the thermostat reloads the control parameter factory settings after
each change of DIP switch setting.
1 2 3 4 5
ON
OFF
Note
