48 / 60
Siemens RDG100…/RDG110…/RDG140.../RDG160… Basic Documentation CE1P3076.en
Building Technologies Functions 28 May 2009
P52 Fan operation 1 0 = Disabled
1 = Enabled
2 = Heating only
3 = Cooling only
P53 Fan speed 3-speed 1 = 1-speed
2 = 3-speed
P54 Fan o verrun time
(only when electr. heater is used)
60 sec 0 ... 360 sec
P55 Switching point fan speed high 100% 80..100%
P55 ECM f an max. o utput ECM: 80% ECM: fan min….100%
P56 Switching point fan speed med 65% 30..75%
P56 ECM fan min. output ECM: 30% ECM: 0%...fan max.
P57 Switching point fan speed low 10% 1..15%
P57 ECM: Switching point fan ECM:10% ECM: 0..100%
P58 Fan start booster ON ON: enabled
OFF: disabled
P59 Fan minimum on time (dwell time) 2 min 1 ... 6 min
P60 Fan kick in Comfort (time until next kick) 0 0…89 min, OFF(90 min)
P61 Fan kick in E-saving mode (time until next kick) OFF 0…359 min, OFF(360 min )
P62 Clean filter reminder run-time Off (0) Off, 100 … 9900 hours
P65 Protection heating setpoint 8 °C OFF, 5 … W Cool Prot;
(W Cool Prot = 40 °C max)
P66 Protection cooling setpoint OFF OFF, W Heat Prot … 40;
(W Heat Prot = 5 °C min.)
P67 Fan start delay in 2P control 0 s 0.. 180 s
P68 Prolong Comfort period OFF OFF; 15 ... 360 min
P69 Temporary setpoint Comfort
(see also Comfort setpoint P08)
OFF OFF = Disabled
ON = Enable
P70 Infrared receiver ON OFF = Disabled
ON = Enabled
P71 Reload factory settings OFF OFF = Disabled
ON = Reload start
Parameter
Name Factory setting Range
RDG100
RDG100T
RDG110
RDG140
RDG160
Diagnostics & test
d01 Application type Diagnostics 0 = (No application)
1 = 2-pipe
2 = 2-pipe with electric heater
3 = 2-pipe with radiator
4 = 4-pipe
5 = 2 stage heat or cool
6 = 4-pipe with electric heater
d02 X1 status Diagnostics 0 = Not activated (for DI)
1 = activated (DI)
0…49 °C = cur. temp. value (for AI)
00 = HC input short
100 = HC input open
d03 X2 status Diagnostics 0 = Not activated (for DI)
1 = activated (DI)
0…49 °C = cur. temp. value (for AI)
00 = HC input short
100 = HC input open
d04 D1 status Diagnostics 0 = Not activated (for DI)
1 = activated (DI)
00 = HC input short
100 = HC input open
d05 Test mode for checking the Y1/Y2
actuator direction
(press left button to escape)
--- “---“ = no signal on outputs Y1 and Y2
OPE = output Y1 forced open
CLO = output Y2 forced closing
d06 Test mode for checking the Y3/Y4
actuator direction
(press left button to escape)
--- “---“ = no signal on outputs Y3 and Y4
OPE = output Y3 forced open
CLO = output Y4 forced closing
Parameter available
Parameter not available
