Siemens RDG100T Basic Documentation

32 / 66
Siemens RDG100, RDG100T, RDG110, RDG140, RDG160 Basic Documentation CE1P3181en
Building Technologies Functions 14 Dec 2011
Modulating control: 3-position or PWM
The diagrams below show the control sequence of modulating PI control.
Heating mode with manual selection (P01=2) Cooling mode with manual selection P01=2)
Y [%]
100
0
w
3181D1124b
T[°C]
XpH
YH
YE
w
D
½ SDH ½ SDH
3181D105b
Y [%]
100
0
w
T[°C]
YC
XpC
Heating and cooling mode (P01=4)
T[°C] Room temperature
w Room temperature setpoint
YE Control. command “El. heater"
(only on/off)
YH Control command “Valve” or “Comp.” (H)
(only PWM, not 3-position)
YC Control command “Valve” or “Comp.” (C)
XpH Proportional band “Heating” (P30)
XpC Proportional band “Cooling” (P31)
X
dz
Dead zone (P33)
Y [%]
100
0
w
3181D114b
T[°C]
YC
XpH
YH
XpC
½
x
dz
½
x
dz
YE
w
D
½ SDH ½ SDH
w
D
Setpoint differential (P34)
The diagrams only show the PI controller’s proportional part.
Setting the sequence and the control outputs
Refer to sections 4.5 ("Applications"), 4.7.1 ("Sequences") and 4.7.2 ("Outputs").
 Y1 can only be on/off or PWM
 Y2 can only be on/off
 Y3 can be on/off, PWM or 3-position
Note
Notes
