Siemens RDG100T Basic Documentation

6 / 66
Siemens RDG100, RDG100T, RDG110, RDG140, RDG160 Basic Documentation CE1P3181en
Building Technologies Summary 14 Dec 2011
2 Summary
2.1 Brief description
 2-pipe fan coil units, 2-pipe with electric heater,
2-pipe with radiator / floor heating
 4-pipe fan coil units, 4-pipe with electric heater
 2-stage heating or cooling application
 Compressors in dx type equipment
 Universal heating and/or cooling
 2 multifunctional inputs and 1 digital input for keycard contact, external sensor,
etc.
 Operating modes: Comfort, Economy and Protection
 Automatic or manual heating / cooling changeover
 Adjustable commissioning and control parameters
 Minimum and maximum setpoint limitation
 Backlit LCD
 Selection of fan stage in the dead zone via P15 (SW V7.2 and higher / device
index E)
 AC 230 V operating voltage, on/off, PWM or 3-position control outputs (triac)
 Output for 3-speed or 1-speed fan
 AC 230 V operating voltage, on/off control outputs (relay)
 Output for 3-speed or 1-speed fan
 AC 24 V operating voltage, DC 0…10 V control outputs
 Output for 3-speed or 1-speed fan
 AC 24 V operating voltage, DC 0…10 V control outputs
 Output DC 0…10 V for fan control
 Infrared remote control receiver
 Auto Timer mode with 8 programmable timers
 Auto timer can be disabled via P02 (SW V7.2 and higher / device index E)
 Landscape design
 Features as RDG100/T, but operating elements (buttons) to the right instead or
below the display
 Maintenance of room temperature via built-in temperature sensor or external
room temperature / return air temperature sensor
 Automatic or manual changeover between heating and cooling mode
 Selection of applications via DIP switches
 Selection of operating mode via the operating mode button on the thermostat
 1-speed, 3-speed or DC…10 V fan control (automatic or manual)
 Display of current room temperature or setpoint in °C and/or °F
 Minimum and maximum setpoint limitation
 Button lock (automatic or manual)
 1 digital input, freely selectable for:
– Operating mode switchover contact (keycard)
– Automatic heating / cooling changeover contact
– Electric heater enable
– Dewpoint sensor
– Fault input
Applications
Features, all types
RDG100, RDG100T
features
RDG110 features
RDG140 features
RDG160 features
Additional RDG100T
features
RDG100T/H features
Functions

Siemens RDG100T Specifications

General

Brand	Siemens
Model	RDG100T
Category	Thermostat
Language	English
