8 Technical data
Rated voltage AC 230 V
Frequency 50/60 Hz
Power consumption
RDG100 / RDG100T / RDG100T/H /
RDG110
Max. 18 VA
2 W / 2 W / 1 W / 1.5 W
Fan control Q1, Q2, Q3-N
Rating
AC 230 V
Max. 5(4) A
Control outputs
Y1, Y2, Y3, Y4-N (RDG100)
Y11-N / /Y21-N (NO) (RDG110)
AC 230 V, max. 1 A
AC 230 V, max. 5(3) A
Multifunctional inputs
X1-M / X2-M
Temperature sensor input
Type
Temperature range
Cable length
Digital input
Operating action
Contact sensing
Parallel connection of several
thermostats for one switch
Insulation against mains
D1-GND
Operating action
Contact sensing
Parallel connection of several
thermostats for one switch
Insulation against mains
QAH11.1 (NTC)
0...49 °C
Max. 80 m
Selectable (NO/NC)
DC 0…5 V, max. 5 mA
Max. 20 thermostats per
switch. Do not mix with D1!
N/A, mains potential
Selectable (NO/NC)
SELV DC 6…15 V, 3…6 mA
Max. 20 thermostats per
switch.
Do not mix with X1 / X2!
3.75 kV, reinforced
insulation
Function input
External temperature sensor, changeover sensor,
operating mode switchover contact, dewpoint
monitor contact, enable electrical heater contact,
fault contact
Selectable
RDG100… / RDG110
Power supply
Outputs
Inputs
