Siemens RDG100, RDG100T, RDG110, RDG140, RDG160 Basic Documentation CE1P3181en
Building Technologies Functions 14 Dec 2011
Parameter
Name Factory
setting
Range
RDG100 RDG100T RDG100T/H RDG110 RDG140 RDG160 Dependen- cies
Expert level
P52 Fan operation 1 0 = disabled
1 = enabled
2 = heating only
3 = cooling only
      
P53 Fan speed 3-speed 1 = 1-speed
2 = 3-speed
    
x P52
P54 Fan overrun time
(only when electric heater is used)
60 s 0...360 s
     
P52, Appl
P55 Switching point fan speed high 100% 80..100%
    
x P52
P55 ECM fan max. output ECM: 80% ECM: fan min…100% x x x x x

P52
P56 Switching point fan speed medium 65% 30...75%
    
x P52
P56 ECM fan min. output ECM: 30% ECM: 0%...fan max. x x x x x

P52
P57 Switching point fan speed low 10% 1...15%
    
x P52
P57 ECM: Switching point fan ECM:10% ECM: 0..100% x x x x x

P52
P58 Fan start booster ON ON: Enabled
OFF: Disabled
    
x P52
P59 Fan min. on time 2 min. 1...6 min
     
P52
P60 Fan kick interval in Comfort mode
(time until next kick)
OFF **) 0…89 min, OFF
     
P52
P61 Fan kick interval in Economy mode
(time until next kick)
OFF 0…359 min, OFF
     
P52
P62 Clean filter reminder running time Off (0) OFF, 100…9900 hours
     
P52
P65 Protection heating setpoint 8 °C OFF, 5…W Cool Prot;
(W Cool Prot = 40 °C max.)
      
P66 Protection cooling setpoint OFF OFF, W Heat Prot…40;
(W Heat Prot = 5 °C min.)
      
P67 Fan start delay in 2P control 0 s 0...180 s
   
x x
P52,
P46, P47
P68 Extension Comfort period OFF OFF; 15...360 min
      
P69 Temporary setpoint Comfort mode
(see also Comfort setpoint P08)
OFF OFF = disabled
ON = enabled
      
P70 Infrared receiver ON OFF = disabled
ON = enabled
x
 
x x x
P71 Reload factory settings OFF OFF = disabled
ON = reload start
      
Parameter
Name Factory
setting
Range
RDG100 RDG100T RDG100T/H RDG110 RDG140 RDG160 Dependen- cies
Diagnostics and test
d01 Application type Diagnostics 0 = (no application)
1 = 2-pipe
2 = 2-pipe with electric heater
3 = 2-pipe with radiator
4 = 4-pipe
5 = 2 stage heating or cooling
6 = 4-pipe with electric heater
      
d02 X1 status Diagnostics 0 = not activated (for DI)
1 = Activated (DI)
0…49 °C = Curr. temp. value (for AI)
Err *)
00
= H/C input closed
100
= H/C input open
      
d03 X2 status Diagnostics 0 = not activated (for DI)
1 = Activated (DI)
0…49 °C = Curr. temp. value (for AI)
Err *)
00
= H/C input closed
100
= H/C input open
      
d04 D1 status Diagnostics 0 = not activated (for DI)
1 = Activated (DI)
00
= H/C input closed
100
= H/C input open
      
d05 Test mode for checking
actuator direction Y1/Y2
(press left button to escape)
--- “---“ = no signal at outputs Y1 and Y2
OPE = output Y1 forced opening
CLO = output Y2 forced closing
  
x x x
P46
d06 Test mode for checking
actuator direction Y3/Y4
(press left button to escape)
--- “---“ = no signal at outputs Y3 and Y4
OPE = output Y3 forced opening
CLO = output Y4 forced closing
  
x x x
P47
d07 Software version ***)
---
Ux.xx is displayed
     
 Parameter available
 Parameter not available
*) If input is parameterized as analog or set to “0": "Err" is displayed when input is out of range (0...49 °C), open or shorted.
**) Thermostats with SW < 7.2 / device index < E: Factory setting = 0
***) RDG100T/H and thermostats with SW 7.2 and higher / device index E
