Siemens RDG100, RDG100T, RDG110, RDG140, RDG160 Basic Documentation CE1P3181en
Building Technologies Technical data 14 Dec 2011
Built-in room temperature sensor
Measuring range
Accuracy at 25 °C
Temperature calibration range
0…49 °C
< ± 0.5 K
± 3.0 K
Settings and display resolution
Setpoints
Current temperature value displayed
0.5 °C
0.5 °C
Operation
Climatic conditions
Temperature
Humidity
As per IEC 721-3-3
Class 3K5
0…50 °C
<95% r.h.
Transport
Climatic conditions
Temperature
Humidity
Mechanical conditions
As per IEC 721-3-2
Class 2K3
25…60 °C
<95% r.h.
Class 2M2
Storage
Climatic conditions
Temperature
Humidity
As per IEC 721-3-1
Class 1K3
25…60 °C
<95% r.h.
conformity
EMC directive
Low-voltage directive
2004/108/EC
2006/95/EC
C-tick conformity to EMC emission standard
AS/NSZ 4251.1:1999
Reduction of hazardous substances
2002/95/EC
Product standards
Automatic electrical controls for household and
similar use
Special requirements for temperature-dependent
controls
Electronic control type
As per EN 60730–1
As per EN 60730–2-9
2.B (micro-disconnection on
operation)
Electromagnetic compatibility
Emissions
Immunity
As per IEC/EN 61000-6-3
As per IEC/EN 61000-6-2
Safety class
RDG100… / RDG110, RDG140
RDG160
II as per EN 60730
III as per EN 60730
Pollution class Normal
Degree of protection of housing IP30 to EN 60529
Connection terminals Solid wires or prepared
stranded wires
1 x 0.4…2.5 mm2
or 2 x 0.4…1.5 mm2
Note: For sensors on inputs X1, X2, or D1, the cable length is max. 80 m
Housing front color RAL 9003 white
Weight RDG100… / RDG110 / RDG140
RDG160
0.30 kg
0.25 kg
Environmental conditions
Standards and directives
General
