Siemens RDG2 KN Series Basic Documentation

Functions
Control parameters
4
138 | 180
A6V11545892_en--_c
4.15.4 Service level parameters
Parameter display depends on selected application and function. Appl means
application. Parameter values are only visible when the device is set as Manager
(M), Subordinate (S) or both identification (✓).
Parameter
Name
Factory setting
Range
RDG20
..KN
RDG26
..KN
Dependencies
Service level
P001
Control sequence
1)
2-pipe:
1 = Cooling only
4-pipe:
4 = Heating and
cooling
0 = Heating only
1 = Cooling only
2 = H/C changeover auto
3 = H/C changeover manual
4 = Heating and cooling
✓
✓
P002
P002
4)
Operation via room operating mode
selector
1)
1
1 = Auto – Protection / Auto - Comfort –
Protection (when there is local scheduler)
2 = Auto - Comfort - Economy - Protection
3 = Auto (Comfort) - Protection Hospitality
M
M
P001,
P005,
P258
P003
4)
Operation via fan operating selector
2)
0
0 = Auto - Manual
1 = Manual
2 = Auto - Manual - Protection
3 = Auto – Protection
M
M
P350,
P258
P004
Unit
0
0 = °C (parameter in °C)
1 = °F (parameter in °F)
✓
✓
‒
P005
4) 6)
Scheduler
OFF
ON = Enabled
OFF = Disabled
M
M
P002,
P258
P006
Measured value correction
0 K
–5…5 K
✓
✓
‒
P007
Humidity value correction
0
-10…0…10 %
✓
✓
‒
P008
Standard display
0
0 = Room temperature
1 = Setpoint
✓
✓
‒
P009
Additional display information
RDG200KN, RDG260KN: 0…5
RDG204KN, RDG264KN: 0…9
0
0 = --- (No display)
1 = °C and °F
2 = Outside temperature
3 = Time of day (12 h)
4 = Time of day (24 h)
5 = Humidity
6 = Indoor air quality (numeric)
5)
7 = Indoor air quality (text)
5)
8 = Humidity and IAQ (numeric)
5)
9 = Humidity and IAQ (text)
5)
✓
✓
‒
P010
Setpoint concept
1
1 = Comfort concept
2 = Energy saving concept
✓
✓
P104
P011
4)
Comfort basic setpoint
21 °C (70 °F)
5…40 °C (41…104 °F)
M
M
P258
P013
Comfort setpoint minimum
5 °C (41 °F)
(P010 = 1): 5 °C (41 °F)...P016-1 K
(P010 = 2): 5 °C (41 °F)...P014-1 K
✓
✓
P010
P014
Comfort setpoint maximum heating
21 °C (70 °F)
P013+1 K…P015-1 K
✓
✓
P010
P015
Comfort setpoint minimum cooling
25 °C (77 °F)
P014+1 K…P016 -1 K
✓
✓
P010
P016
Comfort setpoint maximum
35 °C (95 °F)
(P010 = 1): P013 +1 K...40 °C (104 °F)
(P010 = 2): P015 +1 K...40 °C (104 °F)
✓
✓
P010
P017
4)
Summer time
1
OFF
1 = Europe
2 = Australia
3 = New Zealand
M
M
P258
P019
4)
Economy heating setpoint
15 °C (59 °F)
--- (0), 5 °C…P020 (41 °F…P020)
P020 = 40 °C max. (P020 = 104 °F max.)
M
M
P258
P020
4)
Economy cooling setpoint
30 °C (86 °F)
--- (0), P019…40 °C (P019…104 °F)
P019 = 5 °C min. (P019 = 41 °F min.)
M
M
P258
P023
5
)
Indoor air quality setpoint
1000 ppm
10...2000 ppm
✓
✓
P450
