Note: Appl means application.
1)
When P201/P203 = 1/3/5, P204/P205 = 3/5, P057 & P058 are visible.
2)
When P150, P153 or P155 = 2 and P001 = 2, P059 & P060 are visible.
3)
When P002 ≠ 2, P102 is visible.
4)
Only available for application 2-pipe/2-stage.
5)
When P201 = 3, P206 is visible; P203 = 3, P207 is visible; P204 = 3, P208 is visible; P205 = 3, P209 is
visible.
6)
When P201 = 1, P214 is visible; P203 = 1, P215 is visible.
7)
When
"H/C changeover" function on X1, X2, U1 is selected, P251 is visible.
8)
When
"External temperature limit (AI)" on X1, X2, U1 is selected, P252 is visible.
9)
When application is 4-pipe with 6-port ball valve as changeover and PICV, P400 & P401 are invisible.
10)
If P258 = 0 (Subordinate), the parameter values are not visible. When P450 = 1 or 3, the parameter is
visible.
11)
Only available for applications 2-pipe, 2-pipe with electric heater and 2-pipe with radiator.
12)
If P258 = 0 (Subordinate), the parameter values are visible.
13)
These parameters values are valid for RDG204KN and RDG264KN.
14)
For RDG264KN, when application is 4-pipe/2-stage, the parameter factory setting is 2.
15)
For RDG204KN and RDG264KN, when P258 = 0 (Subordinate), values 0 and 2 are visible.
