Siemens RDG2 KN Series Basic Documentation

Technical data
7
174 | 180
A6V11545892_en--_c
Environmental conditions
Mechanical conditions
Class 2M2
Operation
IEC 60721-3-3
Climatic conditions
Class 3K5
Temperature
0…50 °C
Humidity
< 95 % r.h.
Standards and directives
EU conformity (CE)
A5W00120120A
*
Electronic control type
2.B (micro-disconnection on operation)
RCM conformity
A5W00120121A
*
Safety class
II as per EN 60730
Pollution class
Normal
Degree of protection of housing
IP30 as per EN 60529
Eco design and labeling directives
Based on EU directive 813/2013 (Eco
design directive) and 811/2013 (Labelling
directive) concerning space heaters,
combination heaters, the following
classes apply:
RDG20..KN
● Application with On/Off operation
of a heater
● PWM (TPI) room thermostat, for
use with On/Off output heaters
Class I value 1 %
Class IV value 2 %
RDG26..KN
● Application with On/Off operation
of a heater
● PWM (TPI) room thermostat, for
use with On/Off output heaters
Class I value 1 %
Class IV value 2 %
Meets the requirements for eu.bac certification
See product list at: http://www.eubaccert.eu/licences-by-criteria.asp
Application
Device
Actuator outputs
CA value (K)
License
No.
Fan coil units (2
pipes)
Variable speed fan
RDG20..KN
Thermal actuator
Heating 0.4
Cooling 0.3
220019
RDG26..KN
Motorized DC
Heating 0.1
Cooling 0.1
220020
Fan coil units
(2 pipes,2 wires)
Variable speed fan
RDG20..KN
Thermal actuator
Heating 0.1
Cooling 0.3
220019
RDG26..KN
Motorized DC
Heating 0.1
Cooling 0.1
220020
