RUGGEDCOM RSG907R
Installation Guide
Chapter 5
Technical Specifications
Dimension Drawings 33
90
176.52
162.72
Figure26:Overall Dimensions
185.44
163.12
210.9
38.1
225.44
90
Figure27:Panel Mount Dimensions
