Chapter 5
Technical Specifications
RUGGEDCOM RSG907R
Installation Guide
32 Operating Environment
Section5.5
Operating Environment
The RUGGEDCOM RSG907R is rated to operate under the following environmental conditions.
Ambient Operating Temperature
fg
-40 to 85 °C (-40 to 185 °F)
Ambient Storage Temperature -40 to 85 °C (-40 to 185 °F)
Ambient Relative Humidity
h
5% to 95%
Maximum Altitude 2000 m
f
Measured from a 30 cm (12 in) radius surrounding the center of the enclosure.
g
Operating temperature may vary based on the limitations of installed SFPs. Refer to the RUGGEDCOM SFP Transceiver Catalog [https://
support.industry.siemens.com/cs/ca/en/view/109482309] for SFP temperature ratings.
h
Non-condensing.
Section5.6
Mechanical Specifications
Weight 2.4 kg (5.3 lbs)
Ingress Protection IP40
Enclosure Die Cast Aluminum
Section5.7
Dimension Drawings
NOTE
All dimensions are in millimeters, unless otherwise stated.
