Chapter 6
Certification
RUGGEDCOM RSG907R
Installation Guide
40 EMC and Environmental Type Tests
Section6.2
EMC and Environmental Type Tests
The RUGGEDCOM RSG907R has passed the following Electromagnetic Compatibility (EMC) and environmental
tests.
EMC Type Tests
Test Description Test Levels Severity Levels
Enclosure Contact ± 8 kV 4IEC 61000-4-2 ESD
Enclosure Air ± 15 kV 4
IEC 61000-4-3 Radiated RFI Enclosure Ports 20 V/m
Signal Ports ± 4 kV @ 2.5 kHz, 5 kHz 4
DC Power Ports ± 4 kV @ 2.5 kHz, 5 kHz 4
AC Power Ports ± 4 kV @ 2.5 kHz, 5 kHz 4
IEC 61000-4-4 Burst (Fast Transient)
Earth
Ground Ports
± 4 kV @ 2.5 kHz, 5 kHz 4
Signal Ports ± 4 kV Line-to-Ground
± 2 kV Line-to-Line
4
DC Power Ports ± 2 kV Line-to-Ground
± 1 kV Line-to-Line
3
IEC 61000-4-5 Surge
AC Power Ports ± 4 kV Line-to-Ground
± 2 kV Line-to-Line
4
Signal Ports 10 V 3
DC Power Ports 10 V 3
AC Power Ports 10 V 3
IEC 61000-4-6 Induced (Conducted) RFI
Earth
Ground Ports
10 V 3
IEC 61000-4-8 Magnetic Field Enclosure Ports 100 A/m Continuous
1000 A/m for 1 s
IEC 61000-4-9 Pulse Magnetic Field Enclosure Ports 300 A/m 4
IEC 61000-4-11 Voltage Dips and Interrupts AC Power Ports 30% for 0.5 Cycles
60% for 5 Cycles
100% for 250 Cycles
Signal Ports 30 V Continuous
300 V for 1 s
4IEC 61000-4-16 Mains Frequency Voltage
DC Power Ports 30 V Continuous
300 V for 1 s
4
IEC 61000-4-17 Ripple on DC Power Supply DC Power Ports 15% 4
IEC 61000-4-18 Damped Oscillatory Wave Slow Damped 2.5 kV Common 3
