RUGGEDCOM RSG907R
Installation Guide
Chapter 6
Certification
EMC and Environmental Type Tests 41
Test Description Test Levels Severity Levels
100 kHz or 1 MHz
IEC 61000-4-29 Voltage Dips and Interrupts DC Power Ports 30% for 0.1 s
60% for 0.1 s
100% for 0.05 s
Signal Ports 2 kV (Failsafe Relay Output)
DC Power Ports 2 kV or 2.8kV DC
Dielectric Strength
AC Power Ports 2 kV
Signal Ports 5 kV (Failsafe Relay Output)
DC Power Ports 5 kV
IEC 60255-27
HV Impulse
AC Power Ports 5 kV
EMC Immunity Type Tests per IEEE 1613
NOTE
The RUGGEDCOM RSG907R meets Class 2 requirements for an all-fiber configuration and Class 1
requirements for copper ports. Class 1 allows for temporary communication loss, while Class 2 requires
error-free and interrupted communications.
Test Description Test Levels
Enclosure Contact ± 8 kVIEEE 1613 ESD
Enclosure Air ± 15 kV
IEEE 1613 Radiated RFI Enclosure Ports 35 V/m
Signal Ports ± 4 kV @ 2.5 kHz, 5 kHz
DC Power Ports ± 4 kV @ 2.5 kHz, 5 kHz
AC Power Ports ± 4 kV @ 2.5 kHz, 5 kHz
IEEE 1613 Fast Transient
Earth Ground Ports ± 4 kV
Signal Ports 2.5 kV Common Mode @ 1 MHzIEEE 1613 Oscillatory
DC Power Ports 2.5 kV Common Mode @ 1 MHz
1 kV Differential Mode @ 1 MHz
Signal Ports 5 kV (Failsafe Relay)
DC Power Ports 5 kV
IEEE 1613 HV Impulse
AC Power Ports 5 kV
Signal Ports 2 kV (Failsafe Relay)
DC Power Ports 2.8 kVDC or 2 kV
IEEE 1613 Dielectric
Strength
AC Power Ports 2 kV
IEEE 1613.1
IEC 61000-4-10
Damped
Oscillating
Magnetic Field
Enclosure Ports 100 A/m for 1 s (100 kHz and 1 MHz)
